SCHEDA MADRE X470 AORUS ULTRA GAMING SK AM4

Scheda madre ideale per progettare un PC Gaming ad alte prestazioni.

Con supporto per processori AMD Ryzen su socket AMD AM4, supporto per RAM DDR4, schede grafiche PCI-Express 3.0, unità SATA 6 Gb / se M. 2 (SATA e PCI-E), la scheda madre ASUS PRIME X470-PRO è all'avanguardia nella tecnologia.

Presa AMD AM4 per processore AMD Ryzen. 4 slot di memoria DDR4 a doppio canale 2666 MHz. 6 porte SATA 6Gb / s + 2 x M. 2 (SATA + PCI-E). 2 porte PCI-Express 3.0 16x + 1 porta PCI-Express 2.0 x16 con supporto multi-GPU AMD CrossFireX a 3 vie (16x / 8x / 4x) e NVIDIA SLI (16x / 8x).

Porte USB 3.0 e USB 3.1. Design aggressivo

Controllo di raffreddamento Fan Xpert. UEFI BIOS semplice da usare e intuitivo. Audio ALC 1220 HD a 8 canali.

• Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
• USB DAC-UP 2 with Adjustable Voltage
• Supports AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation/ 7th Generation A-Series/ Athlon™ X4 Processors
• 2-Way CrossFire/ SLI Graphics Support with Dual Armor and Ultra Durable™ Design
• CEC 2019 Ready, Save Power with a Single Click
• Intel® Ethernet LAN with cFOS Speed Internet Accelerator
• APP Center including EasyTune™ and Cloud Station™ utilities
• Ultra Durable™ 25KV ESD and 15KV Surge LAN Protection
• Anti-Sulfur Resistors Design
• Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
• 8+3 Phase Hybrid Digital PWM Design
• Dual Ultra-Fast M.2 with NVMe PCIe X4 with One Thermal Guard
• RGB FUSION with Multi-Zone LED Light Show design, support Digital LED & RGB LED strips

• Processore
  AM4 Socket:

  1. AMD Ryzen™ processor
  2. AMD 7^th Generation A-series/ Athlon™ processor

  (Please refer "CPU Support List" for more information.)
• Chipset
  1. AMD X470
• Memoria
  1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
  2. Architettura di memoria a doppio canale
  3. Support for DDR4 3200(O.C.) / 3000(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules
  4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  6. Supporta le memorie dotate di Profilo XMP

  ((Per maggiori informazioni fare riferimento alla Lista di memorie compatibili))
• Grafica integrata
  Integrated Graphics Processor:

  1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz*
  2. * Support for HDMI 2.0 version and HDCP 2.2.

  * Actual support may vary by CPU.
  Maximum shared memory of 2 GB
• Audio
  1. Realtek® ALC1220 codec
  2. Audio ad alta definizione
  3. Audio a 2/4/5.1/7.1 canali
  4. Supporta uscite S/PDIF
• LAN
  1. Intel® GbE LAN chip (10/100/1000 Mbit)
• Slot di Espansione
  1. 1 Slot PCI Express 16X,
     operante a 16X

     *Per migliori Performance, se solo una Scheda Video PCI è installata,
     assicurati che questi sia inserita in uno Slot PCI Express 16X.
  2. 1 x Slot PCI Express x16, funzionante a 8X (PCIEX8)
     * Lo Slot PCIEX8 condivide la banda con lo Slot PCIEX16. Quando lo Slot PCIEX8 è utilizzato con una VGAPCI Express, lo Slot PCIEX16 funzionerà a soli 8X.
  3. (Gli Slot PCIEX16 e PCIEX8 sono conformi allo Standard PCI Express 3.0 standard.)
  4. 1 x Slot PCI Express x16, funzionante a x4 (PCIEX4)
  5. * The PCIEX4 slot shares bandwidth with the M2B_SOCKET connector. The PCIEX4 slot becomes unavailable when a device is installed in the M2B_SOCKET connector.
  6. 2 x Slot PCI Express x1
     (Gli Slot PCIEX4 e PCI Express x1 sono conformi allo Standard PCI Express 2.0.)

  * Actual support may vary by CPU.
• Tecnologia Multi GPU
  1. Support for NVIDIA® Quad-GPU SLI™ and 2-Way NVIDIA® SLI™ technologies
  2. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
• Interfaccia di storage
  1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2* SSD support) (M2A_SOCKET)
  2. * Actual bandwidth may vary by CPU.
  3. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe 2.0 x4/x2 SSD support) (M2B_SOCKET)
  4. 6 x SATA 6Gb/s connectors
  5. Support for RAID 0, RAID 1, and RAID 10
• USB
  Chipset:

  1. 1 x USB Type-C™ port with USB 3.1 Gen 2 support, available through the internal USB header
  2. 4 x USB 3.1 Gen 1 ports available through the internal USB headers
  3. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

  CPU:

  1. 4 x USB 3.1 Gen 1 ports on the back panel

  ASMedia® USB 3.1 Gen 2 Controller:

  1. 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support
  2. 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
• Connettori Interni I/O
  1. 1 Connettore di Alimentazione ATX a 24-pin
  2. 1 Connettore di Alimentazione ATX ad 8-pin
  3. 1 Connettore per Ventola della CPU
  4. 1 x water cooling CPU fan header
  5. 4 Connessioni per ventole
  6. 2 x system fan/water cooling pump headers
  7. 2 x digital LED strip headers
  8. 2 x digital LED strip power select jumpers
  9. 1 x CPU cooler LED strip/RGB LED strip header
  10. 2 x M.2 Socket 3 connectors
  11. 6 x SATA 6Gb/s connectors
  12. 1 Connettore per Pannello Frontale
  13. 1 Connettore per uscite Audio Frontali
  14. 1 x S/PDIF Out header
  15. 1 x USB Type-C™ port, with USB 3.1 Gen 2 support
  16. 2 x USB 3.1 Gen 1 headers
  17. 2 x Connettori USB 2.0/1.1
  18. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
      La funzione TPM è opzionale in base alla regolamentazione dei vari stati
  19. 1 x Clear CMOS jumper
  20. 1 x temperature sensor header
  21. 1 x RGB (RGBW) LED strip header
• Pannello Posteriore I/O
  1. 4 x USB 2.0/1.1 ports
  2. 1 x USB Type-C™ port, with USB 3.1 Gen 2 support
  3. 5 x audio jacks
  4. 4 x USB 3.1 Gen 1 ports
  5. 1 x USB 3.1 Gen 2 Type-A port (red)
  6. 1 Porta HDMI
  7. 1 Porta RJ-45
  8. 1 x optical S/PDIF Out connector
• I/O Controller
  1. iTE® I/O Controller Chip
• Monitoraggio H/W
  1. Voltage detection
  2. Temperature detection
  3. Fan speed detection
  4. Water cooling flow rate detection
  5. Overheating warning
  6. Fan fail warning
  7. * Whether the fan speed control function is supported will depend on the fan you install.
• BIOS
  1. 2 x 128 Mbit flash
  2. Use of licensed AMI UEFI BIOS
  3. Support for DualBIOS™
  4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Altre Caratteristiche
  1. Support for APP Center
     * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
     @ BIOS ™
     3D OSD
     Auto Green
     Support for Cloud Station
     EasyTune
     Fast Boot
     Game Boost
     Support for On/Off Charge
     RGB Fusion
     Smart Backup
     Smart Keyboard
     Smart TimeLock
     Smart HUD
     System Information Viewer
     USB Blocker
     USB DAC-UP 2
     V-Tuner
  2. Supporta il Q-Flash
  3. Support for Xpress Install
• Software in Bundle
  1. Norton® Internet Security (OEM version)
  2. cFosSpeed
• Sistema Operativo
  1. Support for Windows 10 64-bit
  2. Support for Windows 7 64-bit
  3. * To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
• Caratteristiche Fisiche
  1. ATX Form Factor; 30.5cm x 24.4cm
